MasaPay
Merchant Interface for Internet Payment

Record of Revised Versions

Version	Date Revised	Author	Version Change
1.0	2013-04-22	Zhou Ying	First draft
1.1	2013-04-24	Zhou Ying	Remove products’ names and descriptions
1.7	2013-06-21	Zhou Ying	Add payment currencies and exchange rates
1.8	2013-07-26	Zhou Ying	Add currencies Modify products’ names and descriptions to 1000
1.9	2013-08-20	Zhou Ying	api order receiving version is upgraded to 1.1 2.4  Add errCode、errMsg on page callback 4.2  Add errCode、errMsg on merchant notification interface
2.0	2013-08-21	Zhou Ying	Gateway version is upgraded to 1.2 2.3  Merchants order submitting interface changes: Add billing address and delivery address 3.3  Merchants payment submitting interface changes: Payment ip is changed to non-null Payment email is changed to non-null Cardholder email is changed to non-null Delivery country, state/city is changed to non-null Name is changed to last name, first name, and signature Add device Fingerprint ID and signature
2.0	2013/9/5	Zhou Ying	Order IP is changed to non-null
2.1	2013/10/22	Zhou Ying	Add 8.api uploading interface of express order
2.2	2013/10/31	Zhou Ying	Modify the following nullable fields into non-null according to the requirements of operation and risk management Internet Payment Business： billFirstName billLastName billAdderess billPostalCode billCountry billState billCity billEmail billPhoneNumber shippingFirstName shippingLastName shippingAdderess shippingPostalCode shippingCity shippingEmail shippingPhoneNumber registerUserEmail registerTime registerIp registerTerminal orderIp orderTerminal API Payment Business： billName billAdderess billPostalCode billCompany billCountry billState billCity billEmail billPhoneNumber shippingAdderess shippingPostalCode shippingcompany shippingCity shippingEmail shippingPhoneNumber deviceFingerprintID registerUserEmail registerTime registerIp registerTerminal orderIp orderTerminal
2.2	2013/12/10	4.2.1	resultCode Add new return types



1       Document Description

1.1  Function Description

Through MasaPay’s payment channel, payers can make payments to merchants directly. Merchant website price use MasaPay supported currencies. Payers use supported currencies of relevant payment methods to make payments.

1.2  Target Readers

MasaPay Internet Payment Merchant Interface document is target to website developers, website maintenance personnel, and website management professionals who have certain website developing abilities and are familiar with one of ASP, PHP, JAVA, ASP.NET and such programming languages and website development of SQL database languages.

2       Internet Collection Business

2.1  Function Outline

Merchant Order Submitting Interface Implements: Merchants submit order information and detail information to MasaPay Internet Order Receiving System.
Implementation of Merchant Notification Interface: Notify merchants about successful order submission after successful payment.

2.2  System Interaction

Figure 2.1System interaction figure


商户系统	Merchant system
MasaPay系统	MasaPay system
seq支付请求	seq payment request
1.构造请求数据	1. Construct request data
2. 调用《商户提交订单接口》发送请求	2. Call Merchant Order Submitting Interface to send request
3. 请求的交易	Requested business
seq支付通知	seq payment notification
4. 通知支付结果，见《通知商户接口》	4. Notify payment results, see Merchant Notification Interface
5. 接收后应答，见《商户应答》	5. Response after receiving, see Merchant Response
6. 对相应的数据进行处理	6. Process relevant data



2.3  Merchant Order Submitting Interface

Initiator: Merchant system
Recipient: MasaPay Internet Order Receiving Interface
Submission type: POST
Produce submitting address:
https://mas.masapay.com/mas/receiveMerchantOrder.htm
Test submitting address:
https://mas-sandbox.masapay.com/mas/receiveMerchantOrder.htm
Submission parameters:

Parameter	Parameter Name	Data Type	Parameter Description	Whether can be null
Basic Parameter
version	Version no.	String(4)	Gateway version number. This version is 1.2.	No
merchantId	Merchant ID	String(32)	Allocate by MasaPay when merchant opens account.	No
charset	Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
signType	Signature type	String(8)	Select SHA256 or MD5	No
Business Parameter
merchantOrderNo	Merchant order no.	String(256)	Unique order number in merchant websites to ensure the uniqueness in merchant system.	No
goodsName	Merchant name	String(1000)	Product name	No
goodsDesc	Product description	String(2000)	The format is: product name 1^product specification 1^purchase quantity 1^product price 1^product display website 1|product name 2^product specification 2^purchase quantity 2^product price 2^product display website 2|……	No
currencyCode	Currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro	No
orderAmount	Order amount	String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.	No
payMode	Payment mode	String(2)	Fill out 10 International credit cards 20 local third party payment 30 offline remittance 90 UnionPay payment	Yes
orgCode	Payment organization code	String(10)	Fill out International credit cards: VISA, MASTER, JCB, AME, DINERSCLUB, DISCOVER Local third party payment: WEBMONEY，QIWI，WALLETONE，PAYON Offline remittance: WESTERNUNION , MONEYGRAM UnionPay payment: UPOP	Yes
payerAuth	Whether payment is authorized	String(1)	Y verification N no verification, the default is no verification	Yes
directFlag	Whether connect directly	String(1)	N non-direct D direct E embedded	No
allowDuplicate	Whether allow duplicated payment	String(1)	Y allow N don’t allow, the default is not allow	Yes
submitTime	Submitting time	String(14)	year month day hour minute second eg: 20121117020101	No
expiryTime	Expiry time	String(14)	year month day hour minute second eg: 20121117020101	Yes
pageUrl	Front desk call back URL	String(256)	For jumping to merchant appointed URL after payment is completed	Yes
bgUrl	Notify URL	String(256)	The address for notifying merchant order submitting results	Yes
ext1	Extended fields	String(256)	Return the parameter when notifying merchant about order payment results, cannot include =, & and such special characters.	Yes
ext2	Extended fields	String(256)	Return the parameter when notifying merchant about order payment results, cannot include =, & and such special characters.	Yes
remark	Remark	String(256)	For transmission of merchant special business information, only valid when merchant and masapay have agreement. Format: parameter name 1^parameter valud 1|parameter name 2^parameter value 2|	Yes
Billing Information
billFirstName	Billing first name	String(100)	Billing first name	No
billLastName	Billing last name	String(100)	Billing last name	No
billAdderess	Billing address	String(200)	Billing address	No
billPostalCode	Billing postcode	String(20)	Not exceed 20 digits	No
billCompany	Billing company name	String(200)	Billing company name	Yes
billCountry	Billing country	String(20)	Billing country ISO Standard Country Codes	No
billState	Billing state/province	String(20)	Mandatory for the United States and Canada, can be null for other countries two-character state,province, or territory codes.	No
billCity	Billing city	String(20)	Billing city	No
billEmail	Billing email	String(100)	Billing email	No
billPhoneNumber	Billing Tel	String(20)	Numbers only, not exceed 20 digits	No
Shipping Information
shippingFirstName	Shipping first name	String(100)	Shipping first name	No
shippingLastName	Shipping last name	String(100)	Shipping last name	No
shippingAdderess	Shipping address	String(200)	Shipping address	No
shippingPostalCode	Shipping postcode	String(20)	Not exceed 20 digits	No
shippingCompany	Shipping company name	String(200)	Shipping company name	No
shippingCountry	Shipping country	String(20)	Shipping country ISO Standard Country Codes	No
shippingState	Shipping state/province	String(20)	Mandatory for the United States and Canada, can be null for other countries two-character state,province, or territory codes.	No
shippingCity	Shipping city	String(20)	Shipping city	No
shippingEmail	Shipping email	String(100)	Shipping email	No
shippingPhoneNumber	Shipping Tel	String(20)	Numbers only, not exceed 20 digits	No
Risk Control Parameter
registerUserId	Register user ID	String(20)	Unique ID for merchant website customer	Yes
registerUserEmail	Register user email	String(60)	Register user email	No
registerTime	Register time	String(14)	year month day hour minute second eg: 20121117020101	No
registerIp	Register IP	String(20)	eg: [202.96.209.16]	No
registerTerminal	Register terminal device	String(20)	00 PC 01 Cell phone 02 Others	No
orderIp	Order IP	String(20)	IP address when payers submit order eg: [202.96.209.16]	No
orderTerminal	Terminal device	String(20)	Terminal device when payers submit order 00 PC 01 Cell phone 02 Others	No
ext3	Extension	String(256)	Extension fields	Yes
ext4	Extension	String(256)	Extension fields	Yes
signMsg	Signature	String(256)	See signature element description	No

Signature element description：
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&goodsName=Women’s Clothing &goodsDesc=product name 1^product specification 1^purchase quantity 1^product price 1^product display website 1|product name 2^product specification 2^purchase quantity 2^product price 2^product display website
2&currencyCode=USD&orderAmount=1000&payMode=20&orgCode=WEBMONEY&directFlag=D&allowDuplicate=N&submitTime=20121117020101&expiryTime=20121117030101&pageUrl=https://www.masapay.com&bgUrl=https://www.masapay.com&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

2.4  Page Callback

Initiator: Internet Order Receiving Interface
Recipient: Merchant system
Notification Address: pageUrl+POST request provided when merchant make an order
Parameter:

Parameter	Parameter Name	Data Type	Parameter Description	Whether can be null
Business Parameter
merchantOrderNo	Merchant order no.	String(64)	Unique order number in merchant websites to ensure the uniqueness in merchant system.	No
masapayOrderNo	Business serial no.	String(16)	MasaPay system business serial no.	No
currencyCode	Currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro	No
orderAmount	Order amount	String(18)	Monetary unit Yuan	No
payCurrencyCode	Payment currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro	No
payAmount	Order amount	String(18)	Monetary unit Yuan	No
rates	Exchange rate	String(20)	Be accurate 5 digits after dot	No
resultCode	Result	String(4)	10 Successful payment 11 Unsuccessful payment 12 Payment processing	No
errCode	Error code	String(10)	Error code returned when unsuccessful payment is made.	Yes
errMsg	Error message	String(256)	Error message returned when unsuccessful payment is made.	Yes
signMsg	Signature character string	String(256)	See Signature Element Description	No

Note:
Final payment result shall be subject to the notification.

3       API Payment Receiving Business

3.1  Function Outline

Merchant Order Submitting Interface implements: Merchants submit order information and payment information to MasaPay API Order Receiving System.

3.2  System Interaction

Figure 3.1 System interaction figure

商户系统	Merchant system
MasaPay API系统	MasaPay API system
seq订单支付请求	seq order payment request
1. 构造请求数据	1. Construct request data
2. webservice 订单支付请求	2. webservice order payment request
3. 处理订单支付请求	3. Handle order payment request
4. 返回受理结果	4. Return results
seq通知支付结果	seq notify payment results
5. 通知商户支付成功	5. Notify merchant about successful payment
6. 返回OK	6.Return OK
7. 对通知结果进行处理	7. Process notification results



3.3  Merchant Order Payment Interface

3.3.1       Request

Initiator: Merchant system
Recipient: MasaPay API Internet Order Receiving Interface
Produce submitting address:
https://open.masapay.com/masapi/order/ReceiveMerchantOrder?wsdl
Test submitting address:
https://open-sandbox.masapay.com/masapi/order/ReceiveMerchantOrder?wsdl
Submission parameters:

Parameter	Parameter Name		Data Type	Parameter Description	Whether can be null
Basic Parameter
version	Version no.		String(4)	Gateway version number. This version is 1.2.	No
merchantId	Merchant ID		String(32)	Allocate by MasaPay when merchant opens account.	No
charset	Coded character set		String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language		String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
signType	Signature type		String(8)	Select SHA256 or MD5	No
Business Parameter
merchantOrderNo	Merchant order no.		String(256)	Unique order number in merchant websites to ensure the uniqueness in merchant system.	No
goodsName	Merchant name		String(1000)	Product name	No
goodsDesc	Product description		String(2000)	The format is: product name 1^product specification 1^purchase quantity 1^product price 1^product display website 1|product name 2^product specification 2^purchase quantity 2^product price 2^product display website 2|……	No
currencyCode	Currency		String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro	No
orderAmount	Order amount		String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.	No
payerAuth	Whether payment is authorized		String(1)	Y verification N no verification, the default is no verification	Yes
allowDuplicate	Whether allow duplicated payment		String(1)	Y allow N don’t allow, the default is not allow	Yes
submitTime	Submitting time		String(14)	year month day hour minute second eg: 20121117020101	No
expiryTime	Expiry time		String(14)	year month day hour minute second eg: 20121117020101	Yes
bgUrl	Notify URL		String(256)	The address for notifying merchant order submitting results	Yes
ext1	Extended fields		String(256)	Return the parameter when notifying merchant about order payment results, cannot include =, & and such special characters.	Yes
ext2	Extended fields		String(256)	Return the parameter when notifying merchant about order payment results, cannot include =, & and such special characters.	Yes
remark	Remark		String(256)	For transmission of merchant special business information, only valid when merchant and masapay have agreement. Format: parameter name 1^parameter valud 1|parameter name 2^parameter value 2|	Yes
Payment Parameter
payMode	Payment Mode		String(2)	10 International credit cards	No
orgCode	Payment organization code		String(10)	International credit cards : VISA，MASTER，JCB，AME，DINERSCLUB,DISCOVER	No
cardNumber	Card No.		String(19)	Numbers only, not exceed 19 digits	No
cardHolderFirstName	Card holder’s first name		String(100)	Card holder’s first name	No
cardHolderLastName	Card holder’s last name		String(100)	Card holder’s last name	No
cardExpirationMonth	Card expiration Month		String(2)	Numbers only, not exceed 2 digits	No
cardExpirationYear	Card expiration Year		String(4)	Numbers only, not exceed 2 digits	No
securityCode	Security Code		String(3)	Numbers only, not exceed 3 digits	No
cardHolderEmail	Card holder’s email		String(100)	Card holder’s email	No
cardHolderPhoneNumber	Card holder’s tel		String(20)	Numbers only, not exceed 20 digits	Yes
payExt1	Payment extension1		String(100)	Standby	Yes
payExt2	payment extension2		String(100)	Standby	Yes
Billing Information
billName	Billing first name		String(100)	Billing first name	No
billAdderess	Billing last name		String(100)	Billing last name	No
billPostalCode	Billing address		String(200)	Billing address	No
billCompany	Billing postcode		String(20)	Not exceed 20 digits	No
billCountry	Billing company name		String(200)	Billing company name	Yes
billState	Billing country		String(20)	Billing country ISO Standard Country Codes	No
billCity	Billing state/province		String(20)	Mandatory for the United States and Canada, can be null for other countries two-character state,province, or territory codes.	No
billEmail	Billing city		String(20)	Billing city	No
billPhoneNumber	Billing email		String(100)	Billing email	No
Shipping Information
shippingName	Shipping name		String(100)	Name of recipient	No
shippingAdderess	Shipping address		String(200)	Shipping address	No
shippingPostalCode	Shipping postcode		String(20)	Not exceed 20 digits	No
shippingCompany	Shipping company name		String(200)	Shipping company name	No
shippingCountry	Shipping country		String(20)	Shipping country ISO Standard Country Codes	No
shippingState	Shipping state/province		String(20)	Mandatory for the United States and Canada, can be null for other countries two-character state,province, or territory codes.	No
shippingCity	Shipping city		String(20)	Shipping city	No
shippingEmail	Shipping email		String(100)	Shipping email	No
shippingPhoneNumber	Shipping Tel		String(20)	Numbers only, not exceed 20 digits	No
Risk Control Information
deviceFingerprintID	Device finger print ID	String(60)		1．Device finger print ID is session_token session_token Generating rule: m+merchantId+merchantOrderNo+ submitTime 2 Introducing the following url at page js  sandbox environment: https://h.online-metrix.net/fp/check.js?org_id=1snn5n9w&session_id=masapay1{session_token} generating environment: https://h.online-metrix.net/fp/check.js?org_id=k8vif92e&session_id=masapay2{session_token}	No
payerName	Payer name	String(60)		Payer name	Yes
payerMobile	Payer cell phone	String(20)		Payer cell phone	Yes
payerEmail	Payer email	String(60)		Payer email	Yes
registerUserId	Registered user ID	String(20)		The only ID in merchant website	Yes
registerUserEmail	Registered user email	String(60)		Register email at merchant website	No
registerTime	Register time	String(14)		year month day hour minute second eg: 20121117020101	No
registerIp	Register IP	String(20)		eg: [202.96.209.16]	No
registerTerminal	Register terminal device	String(20)		00 PC 01 Cell phone 02 Others	No
orderIp	Order IP	String(20)		IP address when payers submit order eg: [202.96.209.16]	No
orderTerminal	Terminal device	String(20)		Terminal device when payers submit order 00 PC 01 Cell phone 02 Others	No
ext3	Extension	String(256)		Extension fields	Yes
ext4	Extension	String(256)		Extension fields	Yes
signMsg	Signature	String(256)		See signature element description	No

Participated signature element description:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&goodsName=Women’s Clothing &goodsDesc=product name 1^product specification 1^purchase quantity 1^product price 1^product display website 1|product name 2^product specification 2^purchase quantity 2^product price 2^product display website 2&currencyCode=USD&orderAmount=1000 &allowDuplicate=N&submitTime=20121117020101&expiryTime=20121117030101& bgUrl=https://www.masapay.com&payMode=10&orgCode=visa&cardNumber=4000000000000000&cardHolderFirstName=jerry&cardHolderLastName=jin &cardExpirationMonth=09&cardExpirationYear=14&securityCode=780&cardHolderEmail=test@masapay.com&cardHolderPhoneNumber=13788888888 &deviceFingerprintID=HJH*098&*GYUJHG& shippingCountry =US&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

3.3.2       Return

Return data as XML format to merchant.

Parameter	Parameter Name	Data Type	Parameter Description	Whether can be null
Basic Parameter
version	Version no.	String(4)	Gateway version number. This version is 1.2.	No
charset	Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
errCode	Error code	String(10)	Error code returned when unsuccessful payment is made.	Yes
errMsg	Error message	String(256)	Error message returned when unsuccessful payment is made.	Yes
signType	Signature type	String(8)	Select SHA256 or MD5	No
Business Parameter
merchantOrderNo	Merchant order no.	String(64)	Unique order number in merchant websites to ensure the uniqueness in merchant system.	No
masapayOrderNo	Business serial no.	String(16)	MasaPay system business serial no.	No
submitTime	Submission time	String(14)	Time when merchant submit order Year month day hour minute second eg: 20121117020101	No
dealTime	Deal time	String(14)	Time when MasaPay business completed Year month day hour minute second eg: 20121117020101	No
currencyCode	Currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen	No
orderAmount	Order amount	String(18)	Integer Except JYD and KRW as yuan, other currencies as cent	No
payCurrencyCode	Payment currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen	No
rates	Exchange rate	String(20)	Be accurate 5 digits after dot	No
paidAmount	Paid amount	String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.	No
payMode	Payment mode	String(2)	10 International credit cards	No
orgCode	Payment organization code	String(10)	International credit cards: VISA，MASTER，JCB，AME，DINERSCLUB	Yes
resultCode	Result	String(2)	00 Accept 10 Payment succeeded 11 Payment failed	No
riskLevel	Risk level	String(2)	00 None，01 Rejected by risk control，02 Suspicious 03 Business suspended	Yes
riskOccurCount	Cumulative quantity of risk orders	String(4)	Cumulative quantity of risk orders	Yes
riskDesc	Risk description	String(256)	Risk note	Yes
ext1	Extension	String(256)	Return original order merchant submitted ext1	Yes
ext2	Extension	String(256)	Return original order merchant submitted ext2	Yes
signMsg	Signature character string	String(256)	See Signature Element Description	No

Participated signature element description:
version=1.2&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&masapayOrderNo=880111123&submitTime=20121117020101&dealTime=20121117030101&currencyCode=USD&orderAmount=1000&payCurrencyCode=CNY&rates=6.21321&paidAmount=1000&payMode=20&orgCode=WEBMONEY&resultCode=10&riskLevel=00& riskOccurCount=10&riskDesc=norisk&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods


4       Merchant Notification of Payment Result

4.1  Function Outline

Merchant Notification Interface implements: Notify merchant about system order payment is successful after successful payment.

4.2  Merchant Notification Interface

4.2.1       Callback Merchant’s URL

Initiator: Internet Order Receiving Interface
Recipient: Merchant system
Notification address: bgUrl + POST request provided by merchant when making order
Parameter:

Parameter	Parameter Name	Data Type		Parameter Description	Whether can be null
Basic Parameter
version	Version no.	String(4)		Gateway version number. This version is 1.2.	No
charset	Coded character set	String(10)		Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language	String(2)		cn Chinese, en English, ru Russian, jp Japanese	No
signType	Signature type	String(8)		Select SHA256 or MD5	No
Business Parameter
merchantOrderNo	Merchant order no.	String(64)		Unique order number in merchant websites to ensure the uniqueness in merchant system.	No
masapayOrderNo	Business serial no.	String(16)		MasaPay system business serial no.	No
submitTime	Submission time	String(14)		Time when merchant submit order Year month day hour minute second eg: 20121117020101	No
dealTime	Deal time	String(14)		Time when MasaPay business completed Year month day hour minute second eg: 20121117020101	No
currencyCode	Currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro		No
orderAmount	Order amount	String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.		No
payCurrencyCode	Payment currency	String(3)		CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen	No
rates	Exchange rate	String(20)		Be accurate 5 digits after dot	No
paidAmount	Paid amount	String(18)		Integer Except JYD and KRW as yuan, other currencies as cent.	No
payMode	Payment mode	String(2)		Fill out 10 International credit cards 20 local third party payment 30 offline remittance 90 UnionPay payment	No
orgCode	Payment organization code	String(10)		Fill out International credit cards: VISA, MASTER, JCB, AME, DINERSCLUB, DISCOVER Local third party payment: WEBMONEY，QIWI，WALLETONE，PAYON Offline remittance: WESTERNUNION , MONEYGRAM UnionPay payment: UPOP	Yes
resultCode	Result	String(2)		10 Successful payment 11 Unsuccessful payment 12 Checking	No
errCode	Error code	String(10)		Error code returned when unsuccessful payment is made.	Yes
errMsg	Error message	String(256)		Error message returned when unsuccessful payment is made.	Yes
riskLevel	Risk level	String(2)		00 None，01 Rejected by risk control，02 Suspicious 03 Business suspended	Yes
riskOccurCount	Cumulative quantity of risk orders	String(4)		Cumulative quantity of risk orders	Yes
riskDesc	Risk description	String(256)		Risk note	Yes
ext1	Extension	String(256)		Return original order merchant submitted ext1	Yes
ext2	Extension	String(256)		Return original order merchant submitted ext2	Yes
signMsg	Signature character string	String(256)		See Signature Element Description	No

Signature element description:
version=1.2&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&masapayOrderNo=880111123&submitTime=20121117020101&dealTime=20121117030101&currencyCode=USD&orderAmount=1000&payCurrencyCode=CNY&rates=6.21321&paidAmount=1000&payMode=20&orgCode=WEBMONEY&resultCode=10&riskLevel=00& riskOccurCount=10&riskDesc=norisk&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

4.2.2       Merchant Response

MasaPay notifies merchant through bgUrl in back stage. After handled by merchant system, it needs to be sent back to MasaPay system as character string format. The content is as following:

Return	Description
OK	Successful. MasaPay system will not resend notice if receives this result.
No return or other character	Unsuccessful, MasaPay system will re-notify if receives this result.



5       API Inquiry Business of Collection Order

5.1  Function Outline

Merchant Inquiry Interface implements: Search for MasaPay transaction records in a certain period or any transaction record on merchant website.

5.2  System Interaction

商户系统	Merchant system
MasaPay系统	MasaPay system
1. 构造请求数据	1. Construct request data
2. 调用《商户提交订单接口》发送请求	2.Call Merchant Order Submitting Interface to send request
3. 请求处理	3. Request for solutions
4. 返回结果	4. Return results
5. 对相应的数据进行处理	5. Process relevant data



5.3  Merchant Query Interface

5.3.1       Request

Produce submitting address:
https://open.masapay.com/masapi/order/QueryMerchantOrder?wsdl
Test submitting address:
https://open-sandbox.masapay.com/masapi/order/QueryMerchantOrder?wsdl
Input Parameter:

Parameter		Parameter Name	Data Type	Parameter Description	Whether can be null
Basic Parameter
version		Version no.	String(4)	Gateway version number. This version is 1.2.	No
merchantId		Merchant ID	String(32)	Allocate by MasaPay when merchant opens account.	No
charset		Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language		Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
signType		Signature type	String(8)	Select SHA256 or MD5	No
Business Parameter
queryType	Query Type		String(1)	0 query for individual according to MasaPay business serial no. 1 according to merchant order no. 2 bulk query according to business ending time, successful orders only	No
masapayOrderNo	Business serial no.		String(16)	Fill out when query type is 0	Yes
merchantOrderNo	Merchant order no.		String(64)	Fill out when query type is 1	Yes
startTime	Starting time of order submission		String(14)	Fill out when query type is 2 Year month day hour minute second eg: 20121117020101	Yes
endTime	Ending time of order submission		String(14)	Fill out when query type is 2 Year month day hour minute second eg: 20121117020101 Limited time period is 14 days, and spacing is 24 hours.	Yes
signMsg	Signature character string		String(256)	See Signature Element Description	No

Note:
If merchant has duplicated submission, there would be more results according to merchant order number.
Signature element description：
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&queryType=1&merchantOrderNo=10000121&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

5.3.2       Return

Send data back to merchant as XML.

Parameter	Parameter Name	Data Type	Parameter Description		Whether can be null
Basic Parameter
version	Version no.	String(4)	Gateway version number. This version is 1.2.		No
merchantId	Merchant ID	String(32)	Allocate by MasaPay when merchant opens account.		No
charset	Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS		No
language	Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese		No
signType	Signature type	String(8)	Select SHA256 or MD5		No
errCode	Error code	String(10)	Error code returned when unsuccessful payment is made.		Yes
errMsg	Error message	String(256)	Error message returned when unsuccessful payment is made.		Yes
recordCount	Record count	String(10)	Record count		No
signMsg	Signature character string	String(256)	See Signature Element Description		No
Order Information (list)
merchantOrderNo	Merchant order no.	String(60)	Unique order number in merchant websites to ensure the uniqueness in merchant system.		No
masapayOrderNo	Business serial no.	String(16)	MasaPay system business serial no.		No
orderAmount	Order amount	String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.		No
orderTime	Submission time	String(14)	Time when merchant submit order Year month day hour minute second eg: 20121117020101		No
dealTime	Deal time	String(14)	Year month day hour minute second eg: 20121117020101		No
status	Order status	String(1)	N not paid S paid successful F paid failed I during payment C closed		No
payMode	Payment mode	String(2)	10 International credit cards 20 local third party payment 30 offline remittance 90 UnionPay payment		Yes
orgCode	Payment organization code	String(10)	Fill out International credit cards: VISA, MASTER, JCB, AME, DINERSCLUB, DISCOVER Local third party payment: WEBMONEY，QIWI，WALLETONE，PAYON Offline remittance: WESTERNUNION , MONEYGRAM UnionPay payment: UPOP		Yes
paidAmount	Paid amount	String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.		No
currencyCode	Currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro	No
payCurrencyCode	Payment currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro		No
rates	Exchange rate	String(20)	Be accurate 5 digits after dot		No
riskLevel	Risk level	String(2)	00 None，01 Rejected by risk control，02 Suspicious 03 Business suspended		Yes
riskOccurCount	Cumulative quantity of risk orders	String(4)	Cumulative quantity of risk orders		Yes
riskDesc	Risk description	String(256)	Risk note		Yes
OrdersignMsg	Signature character string	String(256)	See Signature Element Description		No

Participated signature element description:
signMsg=SHA256(version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256& recordCount=1&key={key}
OrdersignMsg signature element description:
merchantOrderNo=10000121&masapayOrderNo=880111123&orderAmount=1000&orderTime=20121117020101&dealTime=20121117020101&status=S&payMode=20&orgCode=WEBMONEY&paidAmount=1000&currencyCode=USD&payCurrencyCode=CNY&rates=6.21321&riskLevel=00& riskOccurCount=10&riskDesc=norisk&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods


6       API Refund Business

6.1  Function Outline

Merchant Refund Interface: Merchant return all or part of bill of purchasing products or service back to user.
Merchant Refund Notification Interface: Notify merchant of successful refund after completed.

6.2  System Interaction

商户系统	Merchant system
MasaPay系统	MasaPay system
seq退款请求	seq refund request
1. 构造请求数据	1. Construct request data
2. 调用《商户退款接口》发送请求	2. Call Merchant Refund Interface to send request
3. 请求处理	3. Request for solutions
seq退款通知	seq refund notification
4. 通知退款结果《退款通知接口》	Notify refund results, see Refund Notification Interface
5. 接受后应答，见《商户应答》	Response after receiving, see Merchant Response
6. 对相应的数据进行处理	Process relevant data



6.3  Merchant Refund Interface

6.3.1       Request

Produce submitting address:
https://open.masapay.com/masapi/refund/RefundMerchantOrder?wsdl
Test submitting address:
https://open-sandbox.masapay.com/masapi/refund/RefundMerchantOrder?wsdl
Input Parameter:

Parameter		Parameter Name	Data Type	Parameter Description	Whether can be null
Basic Parameter
version	Version no.		String(4)	Gateway version number. This version is 1.2.	No
merchantId	Merchant ID		String(32)	Allocate by MasaPay when merchant opens account.	No
charset	Coded character set		String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language		String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
signType	Signature type		String(8)	Select SHA256 or MD5	No
Business Parameter
refundOrderNo	Refund order no.		String(30)	Unique order number in merchant websites to ensure the uniqueness in merchant system.	No
merchantOrderNo	Original merchant order no.		String(64)	Merchant paid order no.	No
masapayOrderNo	MasaPay Business serial no.		String(16)	MasaPay Business serial no.	Yes
refundAmount	Refund amount		String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.	No
currencyCode	Currency		String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro	No
refundSubmitTime	Refund submission time		String(14)	year month day hour minute second eg: 20121117020101	No
callbackUrl	Callback notify URL		String(256)	Notify callback address that merchant refund order result	No
signMsg	Signature		String(256)	See signature element description	No

Participated signature element description:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&refundOrderNo=0001&merchantOrderNo=10000121&masapayOrderNo=1231221&refundAmount=100&currencyCode=CNY&refundSubmitTime=20121117020101&callbackUrl=http://www.masapay.com&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

6.3.2       Return

Return to merchant the data as XML format.

Parameter	Parameter Name	Data Type	Parameter Description	Whether can be null
Basic Parameter
version	Version no.	String(4)	Gateway version number. This version is 1.2.	No
merchantId	Merchant ID	String(32)	Allocated by MasaPay when registering	No
charset	Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
signType	Signature type	String(8)	Select SHA256 or MD5	No
signMsg	Signature character string	String(256)	See Signature Element Description	No
Business Parameter
resultCode	Refund result	String(2)	10 successful refund 11failed refund	No
errorMsg	Error message	String(256)	Error message returned when failed	Yes
refundOrderNo	Refund order no.	String(32)	the same as refund serial no. when submitting	No

Participated signature element description:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256& resultCode=10& refundOrderNo=123213932&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

6.4  Refund Notification Interface

6.4.1       Notification

Initiator: Internet Order Receiving Interface
Recipient: Merchant system
Notification address: bgUrl + POST request provided by merchant when making order
Parameter:

Parameter	Parameter Name	Data Type	Parameter Description	Whether can be null
Basic Parameter
version	Version no.	String(4)	Gateway version number. This version is 1.2.	No
charset	Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
signType	Signature type	String(8)	Select SHA256 or MD5	No
Business Parameter
refundOrderNo	Refund order no.	String(64)	Unique order number in merchant websites to ensure the uniqueness in merchant system.	No
merchantOrderNo	Original merchant order no.	String(64)	Merchant paid order no.	No
masapayOrderNo	MasaPay Business serial no.	String(16)	MasaPay Business serial no.	Yes
masapayRefundOrderNo	Masapay refund serial no.	String(16)	Masapay refund serial no.	No
submitTime	Submission time	String(14)	year month day hour minute second eg: 20121117020101	No
dealTime	Deal time	String(14)	Time when MasaPay business completed Year month day hour minute second eg: 20121117020101	No
currencyCode	Currency	String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro	No
refundAmount	Refund amount	String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.	No
resultCode	Result	String(2)	10 successful refund 11unsucessful refund	No
ext1	Extension	String(256)	Return original order merchant submitted ext1	Yes
ext2	Extension	String(256)	Return original order merchant submitted ext2	Yes
signMsg	Signature character string	String(256)	See Signature Element Description	No

Participated signature element description:
version=1.2&charset=utf-8&language=en&signType=SHA256&refundOrderNo=0001&merchantOrderNo=10000121&masapayOrderNo=12312312&masapayRefundOrderNo=1111111111111111&submitTime=20121117020101&dealTime=20121117020101&currencyCode=CNY&refundAmount=100&resultCode=10&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

6.4.2       Response

MasaPay notifies merchant through bgUrl in back stage. After handled by merchant system, it needs to be sent back to MasaPay system as character string format. The content is as following:

Return	Description
OK	Successful. MasaPay system will not resend notice if receives this result.
No return or other character	Unsuccessful , MasaPay system will re-notify if receives this result.



7       API Refund Inquiry Business

7.1  Function Outline

Merchant can search for individual transaction record or records on MasaPay in a certain time period.

7.2  System Interaction

商户系统	Merchant system
MasaPay系统	MasaPay system
1. 构造请求数据	1. Construct request data
2. 调用《退款查询接口-请求》	2. Call Refund Inquiry Interface-Request
3. 请求处理	3. Request for solutions
4. 返回结果《退款查询接口-返回》	4. Return results Refund Inquiry Interface-Return
5. 对相应的数据进行处理	5. Process relevant data



7.3  Refund Inquiry Interface

7.3.1       Request

Initiator: Merchant system
Recipient: MasaPay Internet Order Receiving Interface
Produce submitting address:
Test submitting address:
Input Parameter:

Parameter	Parameter Name	Data Type	Parameter Description	Whether can be null
Basic Parameter
version	Version no.	String(4)	Gateway version number. This version is 1.2.	No
merchantId	Merchant ID	String(32)	Allocate by MasaPay when merchant opens account.	No
charset	Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS	No
language	Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese	No
signType	Signature type	String(8)	Select SHA256 or MD5	No
Business Parameter
queryType	Query Type	String(1)	0 query for individual according to MasaPay business serial no. 1 bulk query according to business ending time, successful orders only	No
refundOrderNo	Refund order no.	String(30)	Fill out when query type is 0. The only refund serial no. generated by merchant	No
startTime	Starting time of refund submission	String(14)	Fill out when query type is 2 Year month day hour minute second eg: 20121117020101	Yes
endTime	Ending time of refund submission	String(14)	Fill out when query type is 2 Year month day hour minute second eg: 20121117020101 Limited time period is 14 days, and spacing is 24 hours	Yes
signMsg	Signature character string	String(256)	See Signature Element Description	No

Signature element description:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&queryType=0&refundOrderNo=0001&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods

7.3.2       Return

Return data as XML format to merchant.

Parameter		Parameter Name	Data Type	Parameter Description		Whether can be null
Basic Parameter
version		Version no.	String(4)	Gateway version number. This version is 1.2.		No
merchantId		Merchant ID	String(32)	Allocated by MasaPay when register		No
charset		Coded character set	String(10)	Such as gbk，gb2312，utf-8，Shift-JIS		No
language		Language	String(2)	cn Chinese, en English, ru Russian, jp Japanese		No
signType		Signature type	String(8)	Select SHA256 or MD5		No
errCode		Error code	String(10)	Error code returned when unsuccessful payment is made.		Yes
errMsg		Error message	String(256)	Error message returned when unsuccessful payment is made.		Yes
recordCount		Record count	String(10)	Record count		No
signMsg		Signature character string	String(256)	See Signature Element Description		No
Order Information (list)
refundOrderNo	Refund order no.		String(64)	Unique order number in merchant websites to ensure the uniqueness in merchant system.		No
merchantOrderNo	Original merchant order no.		String(64)	Merchant paid order no.		No
masapayRefundOrderNo	MasaPay refund serial no.		String(16)	MasaPay refund serial no.		Yes
refundAmount	Refund amount		String(18)	Integer Except JYD and KRW as yuan, other currencies as cent.		No
currencyCode	Currency		String(3)	CNY RenMinBi, USD US Dollar, EUR Euro, RUB Ruble, JPY Yen, MOP Macao Pataca, MYR Malaysian Ringgit, NZD New Zealand Dollar, CHF Swiss Franc, THB Thai Baht, TWD New Taiwan Dollar, KRW Korea Won, INR Indian Rupee, CAD Canadian Dollar, AUD Australia Dollar, HKD Hong Kong Dollar, GBP Great Britain Pound, EUR Euro		No
submitTime	Submission time		String(14)	eg: 20121117020101		No
dealTime	Deal time		String(14)	eg: 20121117020101		No
status	Status		String(1)	P Refund processing S Refund succeeded F Refund failed		No
OrdersignMsg	Individual order signature character string		String(256)		Encrypted element for individual order record	No

signMsg signature element description:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&recordCount=1&key={key}
OrdersignMsg signature element description:
refundOrderNo=0001&merchantOrderNo=10000121&masapayRefundOrderNo1111111111111111&refundAmount=100&currencyCode=CNY&submitTime=20121117020101&dealTime=20121117020101&status=P&key={key}
Examples of Signature Methods:
Please see details in Appendix 8.1 Example of Signature Methods


8       API Express Order Uploading Business

8.1  Function Outline

Express Order Uploading Interface implements: Merchant upload express order data.

8.2  Express Order Uploading Interface

8.2.1       Request

Produce submitting address:
https://open.masapay.com/masapi/order/UploadExpressList?wsdl
Test submitting address:
https://open-sandbox.masapay.com/ masapi/order/UploadExpressList?wsdl
Input Parameter:

Parameter	Parameter Name			Data Type		Parameter Description	Whether can be null
Basic Parameter
version	Version no.		String(4)		Gateway version number. This version is 1.2.		No
merchantId	Merchant ID		String(32)		Allocate by MasaPay when merchant opens account.		No
charset	Coded character set		String(10)		Such as gbk，gb2312，utf-8，Shift-JIS		No
language	Language		String(2)		cn Chinese, en English, ru Russian, jp Japanese		No
expressCount	Express order amount		String(10)		Upload express order total amount		No
signType	Signature type		String(8)		Select SHA256 or MD5		No
signMsg	Signature character string			String(256)	See signature element description		No
Express Order Information (list)
merchantOrderNo	Merchant order no.			String(64)	Original merchant payment order no.		No
expressDate	Express date			String(14)	year month day hour minute second eg: 20121117020101		No
etaDate	Estimated delivery date			String(14)	year month day hour minute second eg: 20121117020101		No
expressNo	Express No.			String(32)	Order no. when express company make an order		No
expressCompany	Express company			String(60)	Express company		No
expressUrl	Express order inquiry Url			String(200)	Website where express company search for orders		No
uploadDate	Uploading date			String(14)	year month day hour minute second eg: 20121117020101		No
expressSignMsg		Individual express order signature character string	String(256)		Each express order signature character string		No

Note:
Merchant can upload multiple orders once.
Signature element description:
signMsg=SHA256(version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&expressCount=1&key={key})
ExpressSignMsg Signature element description:
merchantOrderNo=10000121&expressDate=20121117020101&etaDate=20121117020101&expressNo=10099900101&expressCompany=SFexpress&expressUrl=www.masapay.com&key={key}

8.2.2       Return

Return data as XML format to merchant.

Parameter			Parameter Name	Data Type		Parameter Description			Whether can be null
Basic Parameter
version			Version no.	String(4)		Gateway version number. This version is 1.2.			No
merchantId			Merchant ID	String(32)		Allocated by MasaPay when registered.			No
charset			Coded character set	String(10)		Such as gbk，gb2312，utf-8，Shift-JIS			No
language			Language	String(2)		cn Chinese, en English, ru Russian, jp Japanese			No
signType			Signature type	String(8)		Select SHA256 or MD5			No
errCode			Error code	String(10)		Error code returned when unsuccessful payment is made.			Yes
errMsg			Error message	String(256)		Error message returned when unsuccessful payment is made.			Yes
expressCount		Express order amount		String(10)		Total amount received successful orders		No
signMsg			Signature character string	String(256)		See signature element description			No
Unsuccessful Express Order Information list
merchantOrderNo	Merchant order no.				String(64)		Original merchant payment order no.			No
expressDate	Express date				String(14)		year month day hour minute second eg: 20121117020101			No
etaDate	Estimated delivery date				String(14)		year month day hour minute second eg: 20121117020101			No
expressNo	Express No.				String(32)		Order no. when express company make an order			No
expressCompany	Express company				String(60)		Express company			No
expressUrl	Express order inquiry Url				String(200)		Website where express company search for orders			No
uploadDate	Uploading date				String(14)		year month day hour minute second eg: 20121117020101			No
expressSignMsg	Individual express order signature character string			String(256)		Each express order signature character string					No

Signature element description:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256& expressCount =2&key={key}
expressSignMsg Signature element description:
merchantOrderNo=10000121&expressDate=20121117020101&etaDate=20121117020101&expressNo=10099900101&expressCompany=FS express & expressUrl = &key = {key}


9       Appendix

9.1  Examples of Signature Methods

9.1.1       Merchant Order Submission Interface

Signature Calculation Method:
SHA256
Participated Signature Elements:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&goodsName=women’s clothing&goodsDesc= product name 1^product specification 1^purchase quantity 1^product price 1^product display website 1|product name 2^product specification 2^purchase quantity 2^product price 2^product display website 2&currencyCode=USD&orderAmount=1000&payMode=20&orgCode=WEBMONEY&directFlag=D&submitTime=20121117020101&expiryTime=20121117030101&pageUrl=https://www.masapay.com&bgUrl=https://www.masapay.com&key=1234567890
Use SHA256 to the above signature elements and obtain signature result (capitalize when transferring binary system to hexadecimal)vas following:
AD59678D5389974AB6886A3AAB6133FE0BCF1C0BA56E270B71C941F135F00BC0
Examples of Submitting Parameter:
version=1.2&merchantId=88800033122&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&goodsName= women’s clothing&goodsDesc= product name 1^product specification 1^purchase quantity 1^product price 1^product display website 1|product name 2^product specification 2^purchase quantity 2^product price 2^product display website 2&currencyCode=USD&orderAmount=1000&payMode=20&orgCode=WEBMONEY&directFlag=D&submitTime=20121117020101&expiryTime=20121117030101&pageUrl=http://www.masapay.com&bgUrl=http://www.masapay.com&ext1=&ext2=&remark=&payerName=&payerMobile=&payerEmail=&registerTime=&registerIp=&registerTerminal=&receiveName&receiveAddress=&receivePostCode=&receiveTel=&orderIp=&orderTerminal=&ext3=&ext4=&signMsg=AD59678D5389974AB6886A3AAB6133FE0BCF1C0BA56E270B71C941F135F00BC0

9.1.2       Merchant Notification Interface:

Signature Calculation Method:
SHA256
Participated Signature Elements:
version=1.2&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&masapayOrderNo=880111123&submitTime=20121117020101&dealTime=20121117030101&currencyCode=USD&orderAmount=1000&paidAmount=1000&payMode=20&orgCode=WEBMONEY&resultCode=10&riskLevel=00&riskDesc=norisk&key=1234567890
Use SHA256 to the above signature elements and obtain signature result (capitalize when transferring binary system to hexadecimal) as following:
AE403619EA1D5F460F1F4819802AF9F647C3A4169BACF3F35ECF081568EC2B94
Examples of Submitting Parameter:
version=1.2&charset=utf-8&language=en&signType=SHA256&merchantOrderNo=10000121&masapayOrderNo=880111123&submitTime=20121117020101&dealTime=20121117030101&currencyCode=US

1.1    Response Code

Response Code defines reporting response when business is failed.

1.1.1    Property

AN-4
Field: None.
Data Field: fixed to 4 digits.

1.2.1    Description

Response Code is used for sending authorization status of financial or request authorization transactions. It can also be used in document updating, reconciliation account checking, system management, and receiving status of management transactions. The following is all responding codes and its reasons.

Response codes
MasaPay Code	MasaPay Definition	Code Classification
3084	Insufficient fund	Transaction
3085	Wrong password	Transaction
3086	Violate Encryption Regulations	Risk
3088	Exceed card numbers limit	Risk
3089	Suspicious for cheating	Risk
3091	Wrong bank parameter	System
3092	Invalid transactions	Transaction
3093	Invalid amount	Transaction
3094	Invalid card number	Transaction
3095	Transaction time-out	Transaction
3096	Wrong expiry date	Transaction
3097	Unsupported card types	Transaction
3098	Abnormal system	System
3099	Other abnormal conditions	Others

D&orderAmount=1000&paidAmount=1000&payMode=20&orgCode=WEBMONEY&resultCode=10&riskLevel=00&riskDesc=norisk&ext1=&ext2=&signMsg=AE403619EA1D5F460F1F4819802AF9F647C3A4169BACF3F35ECF081568EC2B94

9.2  Contact

9.3  Agreement

1     MasaPay will not add signs for returned report when returned report has errorCode. At the same time, relevant MasaPay transaction information will be returned as null.

Unitrans世联翻译公司在您身边,离您近的翻译公司,心贴心的专业服务,专业的全球语言翻译与信息解决方案供应商,专业翻译机构品牌。无论在本地,国内还是海外,我们的专业、星级体贴服务，为您的事业加速！世联翻译公司在北京、上海、深圳等国际交往城市设有翻译基地，业务覆盖全国城市。每天有近百万字节的信息和贸易通过世联走向全球！积累了大量政商用户数据，翻译人才库数据，多语种语料库大数据。世联品牌和服务品质已得到政务防务和国际组织、跨国公司和大中型企业等近万用户的认可。 专业翻译公司,北京翻译公司,上海翻译公司,英文翻译,日文翻译,韩语翻译,翻译公司排行榜,翻译公司收费价格表,翻译公司收费标准,翻译公司北京,翻译公司上海。
